Model: XHD-55/80/55-1850
Suitable for producing:
1) stretch film rolls with below specs
* 2~5 KGS/roll small hand use stretch film rolls.
* 10~18 KGS/roll machine use stretch film rolls.
* Medium size rolls with roll weight around 33.5 KGS at 500 mm film width.
2) 8~10 microns 250~500 mm PE cling film rolls.
3) 30~35 microns 250 mm/300 mm/500 mm/750 mm silage film rolls (UV protective film rolls).
| Quantity: | |
|---|---|
XHD-55-80-55-1850
No. | Item | Description |
1) | Model: | XHD-55/80/55-1850 |
2) | Industrial Power Supply: | 3 phases industrial power supply |
3) | Total Installation Power: | 120 KW (for the machine only) |
4) | Main Raw Material: | LLDPE, LDPE (few) & MLLDPE |
5) | Thickness of Film: | 8-50 μm |
6) | Width of the Useful Film: | Maximum 1500 mm |
7) | Film Layer Structure: | CBA 3 layers or CABAC 5 layers |
8) | Designed Linear Speed: | 200 M/min |
9) | Extrusion Output: | 130-200 Kg/H |
10) | Dimensions (L×W×H): | 12.5*5.5*4.6 M (for reference only!) |
11) | Gross Weight: | 12,000 Kg (for reference only) |
Looking to produce cling films that stick firmly and protect goods effectively? Our High-Adhesion Cast PE Cling Film Extruder is the perfect solution. Designed for food packaging, retail, and industrial applications, this extruder creates films with excellent adhesion and clarity. Let’s explore its key benefits!
We engineered this extruder with three core features to meet your cling film needs:
High-adhesion technology for secure wrapping: The unique extrusion process creates films that cling tightly to any surface, preventing slippage during transport or storage. Ideal for irregular-shaped items, it eliminates the need for additional tapes or straps.
Premium PE material for clarity and durability: The extruder uses high-quality polyethylene (PE) to produce films that are clear, flexible, and resistant to punctures. Food-grade options are available, making them safe for direct contact with fruits, vegetables, and meats.
Adjustable thickness for versatile use: Produce films in 10-30 micron thicknesses to suit different needs. Thinner films are perfect for delicate foods, while thicker ones work for heavy industrial goods.
Where will this extruder make an impact? Here are common uses:
Food packaging: Create cling films for wrapping sandwiches, cheese, or fresh produce. The high adhesion keeps packages sealed, preserving freshness and preventing contamination.
Retail product display: Make clear cling films for showcasing toys, electronics, or household items. The film’s clarity highlights product features, while the adhesion keeps packaging tight and professional.
Industrial part protection: Produce durable cling films for wrapping metal parts, tools, or small machinery. The strong adhesion prevents parts from shifting, reducing damage during shipping.
We focus on making your workflow simple:
Automatic tension control: The machine adjusts film tension in real time, ensuring consistent adhesion and stretch. No more manual adjustments—just set your desired adhesion level and let it run.
Quick material changeover: Switch between different PE grades or additives (like anti-fog or UV protection) in minutes. The intuitive control panel lets you update settings with just a few clicks.
Here’s why customers choose us:
1. Compliance with food safety standards: Our extruder produces films that meet FDA and EU food contact regulations. You can confidently use them for food packaging without worrying about safety.
2. Customizable adhesion levels: Work with our engineers to adjust the extrusion process for your specific adhesion needs—whether you need extra-sticky films for heavy loads or light cling for delicate items.
3. Dedicated support team: Our experts provide on-site installation, operator training, and 24/7 remote support. We’re here to ensure your extruder runs smoothly from day one.
Don’t settle for weak cling films that slip or tear. Our High-Adhesion Cast PE Cling Film Extruder lets you produce reliable, high-quality films that meet the demands of any packaging task. Ready to enhance your product protection and presentation? Contact us today to learn how we can help your business!
